Metal Tubular Products 304 Stainless Steel Sheet is one of the most versatile and commonly used stainless steels on the market, Grade 304 stainless steel is the most standard used alloy of this type. Essentially, Grade 304 is an austenitic chromium alloy which is also known as an "18/8" stainless as the make-up of the steel is 18% chromium and 8% nickel. The chromium content promotes the material's considerable resistance to the effects of corrosion and oxidation. The stainless steel alloy resists most oxidizing acids and will withstand ordinary rusting though this does not mean that the steel will not tarnish over time. The steel needs to be cold worked to generate higher tensile strength. For stainless steel sections which are welded heavily, post-weld annealing may be necessary to provide maximum corrosive resistance.
Type 304 and Type 304L have very similar chemical and mechanical properties and are often included on a single material test certificate when the actual properties of a stainless steel plate meet the criteria of both types. This is a very common occurrence. Type 304L is a variation of Type 304 and has a lower carbon content which improves weldability and lowers the risk of reduced corrosion resistance around the weld. Type 304L also has a slightly lower yield and tensile strength than Type 304. As with most steel plate products a number of different designations are used for these steels. The most common are:
Steel and Alloys is specialist distributor, processor and supplier of stainless steel sheets in grade 201, 304, 304L, 316L, 409, and 430 stainless steels in all finishes. We are suppliers of ASTM A240 Stainless Steel 304/304L Sheets made by world’s leading mills, such as Jindal Stainless Ltd., Outokumpu, POSCO, DKC- Korea, European Mills, NTK- Japan, TISCO, Aperam and others. We can supply cut to size ASTM A240 Stainless Steel 304/304L Sheets, with both narrow and wide widths.
Largest Inventory
Customer Support
On Time Deliveries
ISO 9001 : 2015 Certified
Specification:
| Property | Stainless Steel 304 |
| Material | Stainless Steel (SS 304) |
| Type | Austenitic Stainless Steel |
| Composition | Chromium (Cr): 18.0 - 20.0% |
| - | Nickel (Ni): 8.0 - 10.5% |
| - | Carbon (C): 0.08% max |
| - | Manganese (Mn): 2.00% max |
| - | Phosphorus (P): 0.045% max |
| - | Sulfur (S): 0.030% max |
| - | Silicon (Si): 0.75% max |
| Standard | ASTM A240, ASTM A276, ASTM A312, ASTM A213 |
| - | UNS S30400 |
| Mechanical Properties | Tensile Strength: 515 MPa (74,700 psi) |
| - | Yield Strength: 205 MPa (29,800 psi) |
| - | Elongation: 40% |
| Hardness (Brinell) | 201 HB max |
| Hardness (Rockwell B) | 92 HRB max |
| Modulus of Elasticity | 193 GPa (28,000 ksi) |
| Poisson's Ratio | 0.29 |
| Density | 8.0 g/cm³ (0.289 lb/in³) |
Chemical composition of SS 304 STEEL SHEET
| Element | Composition Range (%) |
| Carbon (C) | 0.08 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.045 max |
| Sulfur (S) | 0.030 max |
| Silicon (Si) | 0.75 max |
| Chromium (Cr) | 18.0 - 20.0 |
| Nickel (Ni) | 8.0 - 10.5 |
Mechanical Properties of SS 304 STEEL SHEET
| Property | Stainless Steel 304 |
| Material | Stainless Steel (SS 304) |
| Type | Austenitic Stainless Steel |
| Composition | Chromium (Cr): 18.0 - 20.0% |
| - | Nickel (Ni): 8.0 - 10.5% |
| - | Carbon (C): 0.08% max |
| - | Manganese (Mn): 2.00% max |
| - | Phosphorus (P): 0.045% max |
| - | Sulfur (S): 0.030% max |
| - | Silicon (Si): 0.75% max |
| Standard | ASTM A240, ASTM A276, ASTM A312, ASTM A213 |
| - | UNS S30400 |
| Mechanical Properties | Tensile Strength: 515 MPa (74,700 psi) |
| - | Yield Strength: 205 MPa (29,800 psi) |
| - | Elongation: 40% |
| Hardness (Brinell) | 201 HB max |
| Hardness (Rockwell B) | 92 HRB max |
| Modulus of Elasticity | 193 GPa (28,000 ksi) |
| Poisson's Ratio | 0.29 |
| Density | 8.0 g/cm³ (0.289 lb/in³) |
Advantages of SS 304 STEEL SHEET
- Good general corrosion resistance and high strength
- Good sulfide stress corrosion resistance
- Resistance to chloride pitting and crevice corrosion
- Higher resistance to chloride stress corrosion cracking
- Easy to weld and conform
Some of Our Specialities that make us a profitable Business Partner for our clients are :
- Customer focused approach
- Superior quality products
- Timely deliverices
- Customize Size & Specification
- Competitive Pricing
Applications Industry
| Pharmaceutical Equipment | Chemical Equipment |
| Sea Water Equipment | Heat Exchangers |
| Heat Exchangers | Gas Processing |
| Condensers | Specialty Chemicals |
| Pulp and Paper Industry | Pharmaceuticals |
